Litter Crystal
Basurero exclusivo para recolectar desechos de nuestras mascotas; el diseño sobrio y de líneas sencillas así como su terminado en cubiertas de lámina lo hacen una pieza que se puede instalar prácticamente en cualquier área urbana. El frente del basurero actúa como tapa con cerradura en la cual se encuentra el orificio circular por donde se depositan los desechos y un gráfico con la figura de un perro, además de contar con bolsas de plástico para recoger los desechos. El armazón exterior está fabricado de acero galvanizado recubierto con pintura poliéster, el recipiente interior, de tamaño intermedio, es de lamina metálica galvanizada.
Resource Download


Dibujo Técnico CAD:
Archivo Técnico PDF:

Specs

General measures​

Color Gris Oscuro o Gris Claro
Material Metal
Finishes Metal galvanizado y pintura poliéster
Measures 26 cm x 26 cm x 98.5 cm/30 lt
Manufacturing Estructura de acero, con cubiertas de lámina y cierre con llave
Author David Karásek, Radek Hegmon
Litter Crystal

Materials.


Steel

The basic material used for the manufacture of most product components is grade 11373 (S235JR) or better grade steel. The tolerances comply with the ISO 2768-1 «m» standard, quality of imperfections according to the EN 25817 «C» standard.

Most of steel parts are processed as follows:

    CNC laser cutting

    CNC bending

    Galvanizing - different methods

    Degreasing by washing at 80oC–iron phosphating (anti-corrosion protection)

    Achromatic passivation (cleaning with distilled water)

    Drying at a temperature of 190oC for 10-20 minutes

    Electrostatic powder coating application​
metallic finishes

All our products go through a series of processes according to the type of material and use, in order to provide the highest possible quality and durability; The combination of these processes is a particular art achieved in years of experience, which only the right technology and raw material allow.



The finishing method is according to the model and part of the product:


  • hot dip galvanized
  • Metallization
  • Zinc Paint​
  • Continuous galvanized
  • Electro-galvanized
  • Polyester paint
